Terraced Design Adds Form and Function to a Sloped Yard

This home originally had a steeply sloped and mostly unusable yard. With the help of a multi-level terraced design, it was converted into a family backyard oasis.

Prior to purchasing this home, an Atlanta family of four saw the potential to create their dream backyard and consulted with a design/build contractor who had a terraced design in place before escrow closed on the home. Construction began immediately after the closing.

The existing backyard included a small terraced section held in place by 6’x6’ timber walls, with the remainder of the mostly unusable yard sloping down to a large wooded pond. The renovation design focused on increasing the functionality of the available space with the help of segmental retaining wall to create four terraced levels: a pool level, a sunken outdoor kitchen pavilion, a secluded fire pit terrace, and a recreational play level for the family’s two children. The project was constructed in four phases.

Phase 1: Structural Walls

Since the design included a pool, the first step of construction was to demolish the timber retaining walls (which weren’t capable of supporting the additional weight), remove a few trees to enlarge the main terraced level, and construct new walls capable of supporting the pool. Mega-Tandem™ Mass Segmental Retaining Wall® was selected for its strength and natural stone appearance and was used to create the structure of the two main terrace levels, as well as coordinating built-in planter boxes. Before the walls were capped, wiring was run for low-voltage hardscape lighting, which would be installed during the final phase.

Planter boxes on the second level were adorned with Azalea bushes. Transitions to each level were constructed with natural stone slab step treads. Hardscape lighting lines all walls to improve evening aesthetics and safety.

Phase 2: Poolscape

The second phase of construction was to dig and form the pool and shoot the gunite pool walls. The design of the kidney-shaped pool includes wedding cake steps, a submerged tanning ledge, swim-up bar stools, a raised eight-person spa, and a vanishing waterfall that overlooks the fire pit terrace below.

The vanishing edge waterfall creates a dramatic backdrop for the cozy fire pit terrace that overlooks the wooded landscape and pond. Wooden posts and handrails for the cable fencing were embedded inside the structure of the retaining walls for stability.

Next came the installation of the paver pool deck, tiered garden walls, and rectangular fire pit. The pool deck extends to walkways that continue around both sides of the home. For these projects, Lafitt® pavers and Tandem® Wall were selected, which both offer a modular ashlar pattern and have a natural stone look that coordinates with the Mega-Tandem retaining walls of the primary structure.

The false-jointed ashlar pattern of the garden walls mimics the look of the paver field. Low-voltage hardscape lighting lines the garden walls for ambiance and safety.

Phase 3: Pavilion

The outdoor kitchen offers multiple cooking spaces and includes an open cabinet under the brick oven for storing wood. The texture of the wall veneer and Lafitt® paver flooring complement the natural stone elements to create a cohesive design.

The next phase was to build the 18’x30’ outdoor kitchen pavilion, which includes an open gabled metal roof, exposed cedar-wrapped beams, and staggered cedar shake siding. The base of each outdoor kitchen counter is constructed with Tandem® Modular Grid and capped with a granite countertop. The Tandem wall units used on Modular Grid incorporate the same face texture and color palette as the Tandem Wall and the Mega-Tandem retaining walls, which allowed all of the walls throughout the outdoor living design to have a cohesive look and feel.

The well-appointed kitchen includes a double sink, double-door refrigerator, kegerator beer dispenser, and multiple cooking surfaces—including a gas grill, Big Green Egg® ceramic grill, and a wood-burning Chicago Brick Oven®. The kitchen also includes ample seating, including a countertop bar that overlooks the pool and faces the swim-up bar, for ultimate pool-side entertaining. Natural stone slab step treads were used to transition to each level—from the house to the pool, down into the outdoor kitchen, to the fire pit terrace, and down to the play structure.

The two-sided bar is capped with a granite countertop and offers dry seating under the pavilion and swim-up seating from inside the pool.

Phase 4: Final Touches & PLay Area

The final phase of the project began with landscaping and trimming out the pool with natural stone coping and pebbled tiling, including the 20-foot-wide vanishing waterfall edge that serves as a dramatic backdrop for the cozy fire pit area and overlooks the picturesque wooded pond. Each of the terraced levels were finished with protective cable fencing, outlined with wooden posts and handrails painted to match the color of the pavilion roof.

Next came the playground installation, which required a fourth level to be terraced. Timber wall was selected to terrace this level to coordinate with the wooden play structure and the surrounding natural wooded landscape.

The final task was to install all of the lighting, including low-voltage hardscape lighting that had been pre-wired during earlier phases, which both added an aesthetic element and improved the safety of the multi-level structure. All electrical elements of entire design—including the hardscape lighting, spa, waterfall, pavilion lighting, and sound system—can all be controlled by an app on the homeowner’s phone.

For a fly-through view of the entire multi-level terraced design, watch the drone video below.

PROJECT TEAM:

Designer: Clint Tucker, PLA
Contractor: Sugar Hill Outdoors, LLC
Engineer: John R. Gehrlich, Jr., PE
Engineering Firm: GeoWerks Engineering, LLC
Pool Construction: Bennett Custom Pool Construction
Play Structure Design/Installation: PlayNation Play Systems, Inc., of Georgia

NEXT WEEK’S BLOG: Come back to the Outdoor Living by Belgard blog to get inspired by winning designs from the 2017 Hardscape North America Project Awards.

November 29, 2017

Rigorous Selection Process Results in Attractive Pool Deck Design for HOA

The Morgan Hill Homeowners Association of Temecula, California, takes pride in its impressive community amenity areas, and they should. In addition to the well-appointed community pool, the development includes an expansive clubhouse with pool tables, ping pong tables, tennis courts and an ample lounge area for watching sporting events.

When the homeowners association decided to upgrade the decking of the community pool, they meticulously perused the products, styles and color selections of multiple paver manufacturers, but ultimately settled on a selection of Belgard pavers at the recommendation of the installer, Modern Paving, of Rancho Cucamonga, California.

The group selected the “bishop hat” shape of Moduline Series™ pavers in the Toscana color blend for the primary paver field, accented with 6″x6″ squares of Moduline in the Sahara color. A total of 12,000 square feet of pavers were installed in a castle parquet pattern, creating an contemporary look that complements the elegant development’s modern architecture while blending well with the natural landscape. The project was installed during the colder months of the year so that use of the pool was not disturbed.

January 12, 2017March 18, 2017

Enter for Your Chance to Win HGTV^® Dream Home 2017

As a proud sponsor of the HGTV Dream Home 2017, we are excited to give you an insider’s look at the transformation of the outdoor living spaces of this coastal retreat on the picturesque St. Simons Island, Georgia. And the best part…you can enter for a chance to win this amazing waterfront home!

ENTER NOW FOR YOUR CHANCE TO WIN!

For this year’s HGTV Dream Home, a dated 3,200 square foot three-bedroom, two-bath Mediterranean-style home was selected and transformed into a modern southern farmhouse that takes advantage of the spectacular waterfront view. As the exclusive hardscape sponsor, Belgard helped make the most of the home’s outdoor living areas. Just take a look at these dramatic before and after exterior images.

Driveway

The cracked driveway was replaced with a new tailored paver driveway, which consists of a two-color blend of Catalina™ pavers laid in a 3-piece modular pattern. The driveway was trimmed with a contrasting sailors course of charcoal-colored Catalina pavers. To tie the look together, the concrete porch was overlaid with coordinating pavers and trimmed with charcoal-colored Bullnose Coping. New Old York™ paver walkways add additional charm and provide paved pathways around the sides of the home.

Backyard

Renovation of the backyard focused on taking advantage of the picturesque landscape and dramatic lakefront views. The existing poured concrete patio was overlaid with Catalina™ pavers to provide a cohesive look that mirrors the entrance to the home. The outdoor living areas were extended with a combination of composite decking and Old York™ pavers to provide a variety of entertaining zones.

Poolscape

The existing poolscape was rehabbed with the help of a two-color blend of Catalina™ pavers and complimentary granite-colored Fountain Head Coping that allows the patio pavers to seamlessly integrate with the pool. The patio was extended with composite decking to provide a relaxing lounge area.

A stylish new built-in gas Bordeaux Grill Island adorns the poolside dining area. The grill island boast the look of stacked stone and is capped with midnight-colored accents that coordinate with the decking and paver tones and provide ample prep and serving space.

The poolscape was also extended on the opposite side with a pergola-covered composite deck that provides additional outdoor dining and relaxation space. The paver and decking tones are all in the transitional brown-grey family to provide a cohesive design scheme that carries through to the interior of the home.

Fire Pit Patio

The pergola-covered deck opens onto a newly added fire pit patio. Old York™ pavers provide the setting for the circular Weston Stone® fire pit and welcoming Adirondack chairs that are soon to become a lucky family’s favorite gathering spot.

To learn more about the HGTV Dream Home 2017, click here.

_{No purchase necessary. Open to legal residents of the U.S., age 21 or older.}_{Void where prohibited. Sweepstakes starts at 9 a.m. ET on 12/28/16 and ends at 5 p.m. ET on 2/17/17. Odds of} _{winning depend on number of entries received. For full official rules, visit} _{www.hgtv.com or send a self-addressed stamped envelope to: “HGTV Dream Home} _{Giveaway 2017”, P.O. Box 52915, Knoxville, TN 37950. Main Sponsor: Scripps} _{Networks, LLC d/b/a Home & Garden Television. HGTV, HGTV Dream Home, HGTV Dream Home Giveaway and their associated logos are trademarks of Scripps Networks, LLC. Photos ©2017 Scripps Networks, LLC. Used with permission; all rights reserved.}

December 21, 2016May 30, 2018

Project Profile:
Heated Permeable Pavers

In colder climates, it’s not uncommon for driveways, walkways or patios to be installed with either a heated pavement system or a permeable pavement system to help control ice buildup. This homeowner, however, chose to combine the two systems into one to create the ultimate ice-management pavement system.

The heated permeable paver driveway immediately melts and drains snow and ice. A heating coil is hidden beneath Belgard Eco-Dublin® permeable pavers, which are laid at a 45-degree angle to the house to add visual interest to the elegant design. Decorative poured concrete curbing coordinates with the charcoal paver accents and sits atop edge restraints, adding both stability and a finished look to the pavement system. Matching curbing also lines the landscape beds throughout the property.

Benefits of a Combined Heated/Permeable Pavement System

With a heated pavement system, snow and ice melt immediately to prevent accumulation, but if the surface is not graded properly, or if the pavement settles or degrades over time, there can be pooling or other issues. In comparison, a permeable system allows melting snow to drain into the joints and down into the subsurface rather than remaining on the surface and refreezing into ice. Typically, a plow clears the bulk of the snow, ice melt is applied, and the water goes away. However, with a combined heated permeable pavement system, no plowing or ice melt is needed. All snow or freezing rain that hits the surface melts and drains immediately. Plus, concrete pavers are more durable than poured concrete or asphalt, ensuring increased longevity of a properly working system. After two winters, the homeowners report that the system is performing beautifully, with no water or snow accumulation whatsoever.

How Does It Work?

Heating cables are laid out in the bedding layer, beneath the pavers. Two heat/moisture sensors, each about the size of a tennis ball, are installed in the pavement to automatically turn the heating cables on when there is both precipitation and a below-freezing temperature. When the system is on, it takes a lot of electricity to heat the 4,300 SF drive and walkway, necessitating the addition of a 400-amp pedestal to operate the system. However, because the sensors require both moisture and freezing temperatures, the system is rarely on.

A layer of sand prevents the pavers from having direct contact with the heating cable, which is laid out in the bedding layer. With direct contact, potential movement by the pavers over time could wear through the cable’s protective coating and short out the entire installation. This is especially important in a vehicular application.

Installing the System

Although, the system was planned to include only 18” of excavation, abnormal site conditions required 36” of excavation. A variable base of aggregate was then installed – 27” of #2 stone, 4” of #57, and 2” of #9. A heating cable was installed within the #9 stone layer. In order to maximize the amount of heat transferred from the heating cable to the pavers, the stone separating the cable and pavers needs as much contact with both as possible. Crushed stone with fines transfers the most heat, but doesn’t drain, so it isn’t used in a permeable installation. Instead, the heating cable manufacturer, Warmzone Radiant, recommended smaller drainage stone (#9) because it has more contact with the cable and transfers more heat than larger stone. A layer of sand was then installed over the aggregate to create a cushion between the heating cable and the pavers. This was done to prevent potential paver movement from wearing through the cable’s protective coating over time, which could short out the entire system. The crew also took extra care during the handling and installation of the cable to safeguard the protective coating and ensure long-term functionality of the system.

A heated permeable paver walkway coordinates with the driveway to create a dramatic entrance to the front of the home. The heated Eco-Dublin pavers provide a safe environment for guests and eliminate the need for snow shoveling and deicing agents.

. . .

2014 HNA Project Award Winner – Residential Concrete Permeable Pavers

Design/build Contractor: Grindstone Hardscapes, Josh & Kristen Graczyk, Owners
Location: Grand Island, Nebraska

August 3, 2016March 10, 2017

Tour the 2016 Coastal Living Showhouse in The Hamptons

As the official hardscape supplier of the 2016 Coastal Living Showhouse located in the heart of the quintessential coastal community of The Hamptons, Belgard is proud to offer you this virtual tour of the outdoor living areas of the elegant coastal cottage — including charming cobbled walks, tailored garden walls, a contemporary poolscape, and an inviting outdoor living room with a gourmet grill station.

To begin our virtual tour, take a step back in time to the cobbled streets of yesteryear, with a stroll down the Old World Paver™ driveway and adjoining walkway (color: Sable Blend).

Next, enter the elegant poolscape, constructed with Stones 2.0 Porcelain Pavers to create a contemporary modular design (color: Pierre Blue). Because Belgard Porcelain Pavers can be installed over a variety of bases, the same pavers were able to be used on the pool deck (traditional paver base) and the adjoining stepping stones (grass base) and porches (concrete base), which helped to create a cohesive outdoor living design.

On your way to the cabana, take in the cozy backdrop of the surrounding garden walls, built with the natural stone look of Tandem® Wall in an ashlar pattern (color: Bella).

Tandem Wall also serves to enclose the relaxing outdoor living room with connecting grill station. Fireplace and grill island pieces from the Bordeaux Series of the Belgard Elements Collection serve as focal points for the inviting outdoor living space (color: Midnight). Stones 2.0 Porcelain Pavers provide the patio flooring for the living room and connect with the pool deck via the stepping-stone walkway.

“The coloring and trim of Belgard’s Midnight Bordeaux Elements flowed very nicely with the rest of the outdoor space, as we were going for a comfortable, coastal look,” said Calais Ongania with landscape design firm Mahoney Associates, Inc.. “To soften up the hardscapes, our team used bluegrass, hydrangea, and other flowers of similar color to tie into the grill and fireplace coloring, but give the backyard a warm feel.”

landscape design team: calais Ongania and nasir molla, Mahoney Associates, Inc.

• • •

For more on the Coastal Living Showhouse, click here. The home will be open to the public through September 4, 2016.

July 29, 2016December 19, 2016

Belgard Provides Charm, Improved Function and Cost Savings for Playground

Every play element of the new Chastain Park playground is designed for group play, from multi-person swings to “racing” slides and harmony stations. (photo: Chastain Park Conservancy)

What happens when kids get involved in the design of a playground? Amazing things! Just ask the community surrounding Atlanta’s Chastain Park. The only public playground serving the 85,000 school-age children within a 5-mile radius, the park’s playground had not been renovated since 2000 and was in dire need of an upgrade. The existing playground had a lot of deficiencies, primarily in that it really only appealed to a small demographic (ages 5-12). The majority of the play structures were too dangerous for smaller children, yet not challenging enough for older children.

A Mega-Tandem™ retaining wall provides an acoustic backdrop for one of the park's harmony stations. (Photo: Carson Matthews) — A Mega-Tandem™ retaining wall provides an acoustic backdrop for one of the park’s harmony stations. (photo: Carson Matthews)

Enter play specialist consultant Cynthia Gentry, an expert in childhood development who met with school children from the surrounding community to begin the design concepts. Kids were asked to imagine what they’d like to see on the playground and put that imagery into drawings, which became the inspiration for the all of the designs.

Gentry then enlisted the help of another consultant, Robin Moore, who specializes in nature-based play, currently a strong movement in childhood development circles. Together, Gentry and Moore conducted a charrette, or meeting of the minds, with representatives from the private school located inside the park’s grounds, local public schools and pre-schools, civic associations, the Parks Commission, and various members of the community. At the charrette, the group reviewed all of the children’s drawings and synthesized them into rough design concepts. A second charrette was held at NC State to compound all of the concepts into one overall design.

Landscape Architect Bill Caldwell took the ball from there, handling permits and turning the master plan into design documents for drainage, utilities, elevation, landscaping, hardscaping, and construction of the restroom pavilion. Caldwell contracted renown water resources engineer consultant, Bill Jorden, to develop the stormwater management plan to meet all of Atlanta’s ordinances for stormwater runoff quality and quantity.

Urbana Stone® permeable pavers throughout the playground manage stormwater, reducing water runoff and reducing pollution. (photo: Chastain Park Conservancy) — Urbana Stone® permeable pavers throughout the playground manage stormwater, reducing both stormwater runoff and pollution. (photo: Chastain Park Conservancy)

“Our goal was to not create a detention pond on a beautiful site of rolling hills and historic oak trees. I also didn’t want to have to convert the flat spaces currently used for open play. Belgard products helped us to avoid these traditional stormwater management strategies,” Caldwell said.

With the help of Belgard Urbana Stone® permeable pavers and Mega-Tandem™ Mass Segmental Retaining Wall™, the team was able to conserve land, meet the stormwater requirements, and save a significant amount of money in the process.

“Because the playground was being built into a hillside, the project required substantial retaining walls, which initially called for poured concrete. We got two Mega-Tandem Walls for the price of one poured concrete wall. Also, using the Mega-Tandem allowed us to value-engineer the pavilion and reduce the amount of poured concrete needed for the foundation. Overall, we saved over $200,000 on the project, factoring the cost savings on the pavilion and the site walls,” Caldwell said.

In addition, the 9,000 square feet of permeable paver walkways controls the amount of rainwater runoff that rolls downhill, which alleviates erosion problems. “An impervious system would have caused a concentration of water flow to the lower elevations, which would have generated more runoff than the original site,” Caldwell said.

Caldwell also notes that the Belgard permable pavers and retaining walls allowed him to create the playground out of what was formerly unusable space. “I love the fact that we took a hillside with a 12-15 degree slope that was basically non-functional and turned it into a 1-acre parkland that is a highly functional and usable space and has become a high-value component of the park,” he said. “We created something out of nothing.”

And what Caldwell considers the best part…this playgound was designed by kids for kids, regardless of age or abilities. The entire playground is ADA compliant, with multiple handicap accessible play elements. “Even the texture of the permeable paver walkway adds a sensory element for children with sensory disabilities, which is not something they would get with a smooth poured concrete sidewalk. Addressing disabilities of multiple spectrums was always part of the discussion from the beginning,” Caldwell said.

Urbana Stone® walkway and rock-climbing wall.

Spider web climbing station.

Stump climbing station.

Handicap accessible treehouse.
