Alys Beach
Belgian Cobble® Provides Old Colonial Aesthetic for First Permeable Paver Road in Panhandle
Every Project Starts with a Purpose
Alys Beach, an unincorporated planned community in Walton County, Florida, is a family dream that came to fruition in 2004. In the late 1970s, Jim Stephens, his wife, Julie, and his father, Elton purchased 158 acres of land on the very secluded Highway 30A in the Florida Panhandle.
They named the land Alys Beach for Elton’s wife. While at the time it was just pure scrub oak, sand and blue water, the family had a vision to develop it into a community dedicated to architectural excellence and a deep respect for the natural environment.
Today, it is a New Urban community that combines Bermudan architecture with courtyard living.
The roadway was a key focus of design and planning because of its potential impact on the environment. “This was a legacy project for the family members, who were adamant from the beginning that sustainability be one of the key components of the development,” said Jim Martelli, civil engineer and managing director, Innerlight Engineering Corporation.
“They wanted the neighborhood to stand the test of time and be the best it could be for the environment. A significant part of that is stormwater management.”
MarieAnne Khoury-Vogt and Eric Vogt (KVA) designed Alys Beach in a New Urbanist style, which is particularly suited to the waterfront location but posed challenges. A New Urbanist plan calls for utilities to be placed under the street, meaning they would be accessed regularly as the town continued to grow.
If asphalt roads were used, sections would need to be cut and replaced each time utilities were accessed, creating an unsightly patchwork. Asphalt also failed to meet the aesthetic and sustainability goals established for the town.
The Challenge
As a research center, the Reserve has incorporated many green building materials and construction techniques over the last decade. Until June 2014, the parking lot area of the Reserve consisted of just over 16,000 SF of impervious asphalt and approximately 2,900 SF of pervious grass pave system. The grass pave system stopped functioning properly due to poor water infiltration likely caused by compaction of the underlying soil or gravel. Parking lot runoff contributed to slope erosion near one of the trails and excess sediment loading into the estuary.
The Solution
Solving for Style, Function, and Durability
For water conservation and to maximize land usage, Martelli and installer Robert Reeder, owner of Stone Scapes, Inc., created the first true permeable road installation in the panhandle, allowing the road to be part of the stormwater system. Belgian Cobble® in a dark gray blend with a granite-like appearance, was chosen as the surface of the permeable system to complement the high-end, old colonial aesthetic of the community.
The product perfectly fit with the aesthetic, need to access utilities without leaving evidence of disturbance, and the very important issue of stormwater management. They have used approximately 900,000 square feet of the Belgian 70mm cobble, 6” pavers to date.
Typically, in a cobblestone roadway, the road base would be crushed concrete, but there is no permeable benefit to that. Instead, they chose washed #57 stone, similar to river rock but with many angular pieces that lock together.
Additionally, nearly half of the base is comprised of gaps, which provide storage space for the water. Martelli calculated that 12” of the #57 stone was suitable to support heavy vehicle loads. The Belgard cobble stone is 2 ¾” thick to achieve the particular vehicle loading requirement.
They chose to use 1 to 1 ½ inches of very small #89 stone for the bed under the cobble and to fill the joints. “Rainfall is absorbed almost immediately into the ground, getting filtered in the process,” Martelli said.
Featured Products
The Result
A Lasting Impression:
The Final Transformation
“Alys Beach is now the model for new urbanist resort planning,” explained project landscape architect Patrick Hodges, noting the appeal of both the aesthetic and functional benefits. “The Belgard permeable pavers are ideal for managing stormwater and have been used successfully to enhance treatment and reduce runoff in several recent projects here in the northwest Florida.”
For nearly 20 years, Belgian Cobble® has helped Alys Beach convey the aesthetic KVA designed for the community while achieving the family’s sustainability goals. As the community continues to grow, so, too, will the permeable road system.
